- Full PLC-controlled
- Automatic filling into open-mounted bags.
- Weighing interval between 25-50 kg.
- Rapid and sensitive weighing with load cells.
- Programmable set value with the intervals of 10 gr.
- Programmable number of bags to be filled.
- Top and bottom tolerance value that is programmable seperately.
- Warning for out of tolerance weighing.
- Level control of upper tank.
- Filling capacity between 12-15 ton/hour depending on material type.
- Viewing the number of bagged bag and material weight.
- Easy calibration with a few touches.
- Alarms against the errors.
| TYPE |
HOPPER |
PAN OF BALANCE |
OUTPUT CAPACITY |
WEIGHING |
| MODEL |
(lt) |
(lt) |
(kg/h) |
(pcs/h) |
| STR 10/25 Single |
1683 |
50 |
3,500-7,500 |
350-300 |
| STR 10/25 Double |
2053 |
2 X 50 |
5,500-12,500 |
550-500 |
| STR 25/50 Single |
1953 |
100 |
8,750-15 ,000 |
350-300 |
| STR 25/50 Double |
2531 |
2 X 100 |
13,750-25,000 |
550-500 |
| STR 15/40 Single |
1502 |
110 |
5,250-12,000 |
350-300 |
| STR 15/40 Double |
2531 |
2 X 110 |
8,250-20,000 |
550-500 |
Packing Machine
